Automatic Gate Openers, Garage Door Openers and French Window Shuttered Doors

GEO 548

ELEGIR LA VARIANTE DEL PRODUCTO
€ 1,290.00EUR

Envío / IVA se calculan a check out y depende de la dirección de entrega

  • Underground motorization 24V dc
  • For 2-leaf swing gates up to 2.5m max 500 kg per leaf
  • Compatible with gate that opens inwards or outwards
  • High-performance control unit with a large variety of functions
  • SOFT STOP: with slowing down and reversing on an obstacle
  • Mains power supply, emergency battery or solar panel
  • DUCO SAFE: the anti-pressure obstacle safety system complies with EU standards
  • ECOLOGICAL: energy saving. absorption in stand-by: only 0.007 A

Ideal for double wing gate up to 2 x 2,5m/8ft  wing length each leaf

24V Underground swing gate opener provide an invisible powerful and safe solution, ideal for ornamental swing gates.
To be installed below grade in a waterproof casing.
Ideal for residential & commercial use

Ensures 100% autonomous use even where AC power is unavailable. Discrete and aestetic purity are obtained with this invisible operator, entirely fitted underground



SOFT STOP

  • The opener stops in both directions decreasing the speed and avoiding unwished banging closing.
  • This prevent from usury and ensure long life to your opener and door.
  • This function prevents the door banging closing

ASR (Autimatic Reversal System)

Thanks to the integrated amperometrical detection system and direction sensor, the opener is provided with an automatic reversal system in case the gate reaches an obstacle, the opener stops immediately and reverses automatically. Highest safety is ensured.

DUCO SAFE

obstacle detection safety system guarantees maximal safety of use to your family

SELF LOCK TECHNOLOGY

The self-locking properties of the spindle increase the protection against a dangerous and unauthorised “pressing” of the gate and the otherwise necessary e-locks for the final positions can be omitted.


  • 2x GEO MOT 24V gearmotor
  • set of fixing brackets opening angle 90°
  • 1x KONTROL 9048/24 large control box with electronic board CTH48/24V, toroidal transformer, integrated radio receiver
  • 2x 6203Roll - 2 buttons 433,92 Mhz  rolling code radio transmitters
  • 1x FLASH7500 - blinking light
  • 1x key for manual emergency release
  • 1x instruction manual
  • 1x warning sign

  • Double speed with SOFT STOP
  • SOFT STOP  adjustment: you can postpose/anticipate the slowdown phase
  • Obstacle detection sensitivity adjustment
  • Inverse movement by obstacle detection while closing
  • Control unit with integrated battery housing compartment
  • Integrated battery charger on board: just ready for connection to 2 x 12V emergency batteries in series connected. In case of power failure works autonomously up to 3 days
  • Integrated solar panel management: the card is a just ready to operate autonomously powered by solar panel. NOTE: add  2 x 12V batteries in series connected + 24V min. 20W solar panel. No extra module needed
  • Low consumption technology: only 0,14W stand-by consumption! Protect the environment, reduces waste of energy and  ensures long lasting autonomy with battery/solar panel use
  • Automatic closing with adjustable time (you can vary the pause time from 1 to 100 seconds) or step-by-step ( push to open/ push to close)
  • Adjustable motor power/ obstacle detection sensivity. By decreasing the power the gate opener will be more sensible in case of impact on an obstacle. The adjustment is very easy:  just need to rotate  potentiometer related to each motor.
  • Status Warning light output: an external wired LED light can be connected to indicate if the gate is open, closed, closing or opening
  • Ideal for a safe, quick and easy  installation: the system is electrocution risk-free.
  • heavy duty opener: can work in continuous cycles  without overheating
  • Adjustment of the time lag between the two doors
  • Pedestrian opening (1 partial opening the wing to allow the pedestrian crossing only) can be controlled by remote control or wired control.
  • Possibility of connecting an external timed courtesy light (example: garden light)
  • The gate is  automatically locked in closed position ( irreversibile system).
  • Electro-lock is not needed, but recommended for wing longer than 2,8m each. Compatible with 24V electric-lock ( Booster required)
  • Made in Italy: All components are manufactured in the company to warranty high quality and reliability.
  • After sale service and assistance provided directly by manufacturer without intermediaries
  • Easy  self-storing  of the remotes controls by pushing one button
  • Safety is ensured by an sensitive amperometrical obstacle detection system and pressure control. Photocells ( safety beans) are no longer mandatory. Photocells  are an optional accessory that can be helpful to prevent scratches to the painting of vehicles left in the vicinity of a moving gate. (EN13241-1: 2003 + A1 ( April 2011 ) EN12453 : 2002 EN12445 : 2000)
  • CE conformity: product certified on all points of the current European regulations. Notify body as NEMKO / INTERTEK test reports & certificates available on request
  • Totally in house designed software and hardware are focused on reduce energy consumption and with attention to the absolute reliability using innovative components of the latest generation as our High quality radio receiver hybrid
  • Ducati chooses to use toroidal transformers only to achieve maximum reliability and safety by power surges and ESD. Our Standard 230V-50Hz transformer is also available in 110V/60Hz version.
  • Manual release system by universal triangular key


Datos técnicos

ELECROMECHANICAL UDERGROUND MOTOR GEO 548


Motor power supply

24V
dc motor   75W
max pushing & power 1200N
IP 67
working cycles limit continuous use / no limits
working temperature -20°C/+55°C
max wing length 2,5m/8ft  each leaf
max.wing weight  500kg/1000lb each leaf
max. opening angle 90° / (up to 180° with  additional accessory  item: GIRO180 )
automatic wing lock  √
manual release system √
Compatible with  gate opening towards outside or inside the property

NOTE: the motor will stop by amperometric detection system: it therefore requires mechanical limits to be installed on the floor to stop the gate wing in the open and closed position.To avoid tmechanical limits to be fixed to the ground consider adding the GEO-FC integrated limits witch is an optional accessory to be adeded to this package. .



CTH48 ELECTRONIC BOARD TECHNICAL DATA

(solar panel & battery management on board)


Main power supply (24V version)



Versatile, operates by 3 type of power supply

  • A.C.
  • By emergency battery 12V  ( 2 x 12V batteries in series connected)
  • By 12V 10W solar panel  ( 24V min 20W solar panel)
toroidal transformer's Watts 105W output 0-12V-24V
protection fuse

√10AF
transformer protection fuse 0,8AT (1,2AT for 110V transformer)
use on single or double wing gate
output services
(24V version)

24V
stand-by power consumption 14mA
radio receiver 2 channels ( 1 for full cycle opening, 1 for pedestrian access- partial 1 wing opening)
remote controls channels storage capacity 20 codes
radio transmission protocol DUCATI rolling code
radio frequency 433,92MHz
remote control automatic learning
on board antenna
external antenna input
automatic closure working mode √ with adjustable pause time up to 100 sec.
step by step working √ one pulse to open; one pulse to close
motor power adjustment √ by potentiometer
SOFT STOP √  adjustable by potentiometer
Speed
 2cm/sec
Obstacle detection safety system (DUCO SAFE)

 √
ASR auto reversal system on obstacle detection  √
Wings time lag adjustment  √
In compliance with EU-CE norms
timerized courtesy light output
output for remote advising light of gate status √ light on while gate is open, light off while gate is closed, fast blinking while closing, slow blinking while opening

flashing light output





√ max. 10W 24W blinks quickly while closing, blinks slowly while opening
electric lock output √  additional  booster needed
safety beam-photocells input (NC contact) √ NC normally closed contact Note: use of special low consumption photocells is recommended: use only DUCATI low consumption photocells model 7120
full cycle START input (NO contact)
pedestrian cycle START input ( NO contact)
Emergency STOP button input (NC contact)

CLICK HERE to download the full instruction manual

ELECTRONIC BOARD wiring diagram:  CTH48 to view installation manual
